Features:
- Ideal for 1/10 on road and 1/8 off road scale applications
- Intermediate aluminum case
- NMB dual main bearings
- Superior waterproof
- 25T output shaft
Specifications:
| Type | Digital |
| Bearing | Dual |
| Motor Type | Coreless |
| Gear Type | Metal |
| Gear Material | Titanium & Steel |
| Control System | Pulse Width Control |
| Working Frequence | 1520μs / 330hz |
| Operating Voltage | dc6.0-8.4v |
| Operating Temperature Range | -10 to + 60 degree |
| Operating Speed | 6.0V: 0.15 sec/60 degrees at no load 7.4V: 0.12 sec/60 degrees at no load 8.4V: 0.10 sec/60 degrees at no load |
| Stall Torque | 6.0V: 25.0kg.cm (347.2 oz/in) 7.4V: 30.0kg.cm (416.6 oz/in) 8.4V: 35.0kg.cm (486.1 oz/in) |
| Potentiometer Drive | Direct Drive |
| Dimensions | 40.7x20.5x38.6 mm /1.60x0.81x1.52 in |
| Weight | 82.5g (2.91 oz) |
| Connector Wire Length | jr 360 mm |
